TMC-7100 is a fluorinated engineered fluid based on HFE-7100 chemistry (methoxy-nonafluorobutane), designed for high-performance industrial applications requiring precision cleaning, thermal stability, and electrical insulation.
The fluid delivers comparable physical and chemical properties to Novec™ 7100, including low viscosity, controlled evaporation rate, non-flammability, and excellent dielectric performance. These characteristics make it suitable for applications where reliable cleaning and cooling performance are critical.
TMC-7100 offers strong solvency for removing oils, grease, flux residues, and particulates from sensitive electronic components and precision assemblies. Its low surface tension allows it to penetrate tight geometries, ensuring effective cleaning even in complex designs.
The fluid is widely used in vapor degreasing systems, immersion cleaning processes, and heat transfer applications where consistent performance and material compatibility are required. It is compatible with a wide range of materials including metals, plastics, and elastomers.
TMC-7100 is compliant with global environmental and safety standards, featuring zero ozone depletion potential (ODP) and low toxicity, making it suitable for modern industrial applications.
It is supplied for OEM and industrial use, supporting both prototype-level requirements and large-scale production environments.
| Property | Novec™ 7100 | TMC-7100 |
|---|---|---|
| Chemical Name | Methoxy-nonafluorobutane (HFE-7100) | Same (HFE-7100) |
| Chemical Formula | C4F9OCH3 | C4F9OCH3 |
| Boiling Point | 61 °C | 61–62 °C |
| Freezing Point | −135 °C | ~−135 °C |
| Molecular Weight | 250 g/mol | 250 g/mol |
| Density (25 °C) | 1.52 g/cm³ | 1.52–1.53 g/cm³ |
| Kinematic Viscosity (25 °C) | ~0.38 cSt | ~0.38–0.40 cSt |
| Surface Tension | ~13.6 dynes/cm | ~13–14 dynes/cm |
| Vapor Pressure (25 °C) | ~25 kPa | ~25–26 kPa |
| Dielectric Strength | >35–40 kV | Similar |
| Dielectric Constant | ~6.3 @ 1 kHz | ~6.2–6.4 |
| Heat of Vaporization | ~112 kJ/kg | ~110–113 kJ/kg |
| GWP (100 yr) | ~320 | Same |
| ODP | Zero | Zero |
| Flammability | Nonflammable | Nonflammable |
| Toxicity / Safety | Low toxicity | Low, REACH compliant |
| Material Compatibility | Excellent | Excellent |
| Applications | Cleaning, heat transfer, degreasing | Same |
